134 / 176 page ![]() 134 AT89C5131 4136B–USB–09/03 USB Registers Table 90. USBCON Register USBCON (S:BCh) USB Global Control Register Reset Value = 00h 765 43210 USBE SUSPCLK SDRMWUP DETACH UPRSM RMWUPE CONFG FADDEN Bit Number Bit Mnemonic Description 7USBE USB Enable Set this bit to enable the USB controller. Clear this bit to disable and reset the USB controller, to disable the USB transceiver an to disable the USB controller clock inputs. 6SUSPCLK Suspend USB Clock Set this bit to disable the 48 MHz clock input (Resume Detection is still active). Clear this bit to enable the 48 MHz clock input. 5 SDRMWUP Send Remote Wake Up Set this bit to force an external interrupt on the USB controller for Remote Wake UP purpose. An upstream resume is send only if the bit RMWUPE is set, all USB clocks are enabled AND the USB bus was in SUSPEND state for at least 5 ms. See UPRSM below. This bit is cleared by software. 4 DETACH Detach Command Set this bit to simulate a Detach on the USB line. The V REF pin is then in a floating state. Clear this bit to maintain VREF at 3.3V. 3UPRSM Upstream Resume (read only) This bit is set by hardware when SDRMWUP has been set and if RMWUPE is enabled. This bit is cleared by hardware after the upstream resume has been sent. 2RMWUPE Remote Wake-Up Enable Set this bit to enabled request an upstream resume signaling to the host. Clear this bit otherwise. Note: Do not set this bit if the host has not set the DEVICE_REMOTE_WAKEUP feature for the device. 1CONFG Configured This bit will be set by the device firmware after a SET_CONFIGURATION request with a non-zero value has been correctly processed. It will be cleared by the device firmware when a SET_CONFIGURATION request with a zero value is received. It is cleared by hardware on hardware reset or when an USB reset is detected on the bus (SE0 state for at least 32 Full Speed bit times: typically 2.7 µs). 0 FADDEN Function Address Enable This bit will be set by the device firmware after a successful status phase of a SET_ADDRESS transaction. It will not be cleared afterwards by the device firmware. It is cleared by hardware on hardware reset or when an USB reset is received (see above). When this bit is cleared, the default function address is used (0). |
|
