Data Sheet
ADBMS1818
TYPICAL PERFORMANCE CHARACTERISTICS
analog.com
Rev. 0 | 17 of 89
Figure 36. VDRIVE vs. Temperature
Figure 37. VDRIVE and V+ Line Regulation
Figure 38. VDRIVE Load Regulation
Figure 39. Discharge Switch On Resistance vs. Cell Voltage
Figure 40. Increase in Die Temperature vs. Internal Discharge Current
Figure 41. Internal Die Temperature Measurement Error vs. Temperature
Figure 42. isoSPI Current (Ready) vs. Temperature
Figure 43. isoSPI Current (Active) vs. isoSPI Clock Frequency
