42 / 182 page  42 4173E–USB–09/07 AT89C5132 Table 38. IPL0 Register IPL0 (S:B8h) – Interrupt Priority Low Register 0 Reset Value = X000 0000b 7 6 5 4 3 2 1 0 - IPLAUD – IPLS IPLT1 IPLX1 IPLT0 IPLX0 Bit Number Bit Mnemonic Description 7 - Reserved The value read from this bit is indeterminate. Do not set this bit. 6 IPLAUD Audio Interface Interrupt Priority Level LSB Refer to Table 33 for priority level description. 5 IPLMP3 MP3 Decoder Interrupt Priority Level LSB Refer to Table 33 for priority level description. 4 IPLS Serial Port Interrupt Priority Level LSB Refer to Table 33 for priority level description. 3 IPLT1 Timer 1 Interrupt Priority Level LSB Refer to Table 33 for priority level description. 2 IPLX1 External Interrupt 1 Priority Level LSB Refer to Table 33 for priority level description. 1 IPLT0 Timer 0 Interrupt Priority Level LSB Refer to Table 33 for priority level description. 0 IPLX0 External Interrupt 0 Priority Level LSB Refer to Table 33 for priority level description. |
|
