Section 19 Serial Communication Interface (SCI, IrDA, CRC)
Rev. 2.00 Sep. 24, 2008 Page 924 of 1468
REJ09B0412-0200
Transmitting
station
Receiving
station A
Receiving
station B
Receiving
station C
Receiving
station D
(ID = 01)
(ID = 02)
(ID = 03)
(ID = 04)
Communication line
Serial
data
ID transmission cycle =
receiving station
specification
Data transmission cycle =
Data transmission to
receiving station specified by ID
(MPB = 1)
(MPB = 0)
H'01
H'AA
[Legend]
MPB: Multiprocessor bit
Figure 19.13 Example of Communication Using Multiprocessor Format
(Transmission of Data H'AA to Receiving Station A)
