Section 28 Power-Down Modes

Rev. 2.00 Sep. 24, 2008 Page 1244 of 1468

REJ09B0412-0200

Bit

Bit Name

Initial

Value

R/W

Module

MSTPA5

R/W

D/A converter (channels 1 and 0)

MSTPA4

R/W

Reserved

This bit is always read as 1. The write value should

always be 1.

MSTPA3

R/W

A/D converter (unit 0)

MSTPA2

R/W

Reserved

This bit is always read as 1. The write value should

always be 1.

MSTPA1

R/W

16-bit timer pulse unit (TPU channels 11 to 6)

MSTPA0

R/W

16-bit timer pulse unit (TPU channels 5 to 0)

• MSTPCRB

Bit

Bit Name

Initial

Value

R/W

Module

MSTPB15

R/W

Programmable pulse generator (PPG_0: PO15 to PO0)

MSTPB14

MSTPB13

R/W

Reserved

These bits are always read as 1. The write value should

always be 1.

MSTPB12

R/W

Serial communications interface_4 (SCI_4)

MSTPB11

R/W

Reserved

This bit is always read as 1. The write value should

always be 1.

MSTPB10

R/W

Serial communications interface_2 (SCI_2)

MSTPB9

R/W

Serial communications interface_1 (SCI_1)

MSTPB8

R/W

Serial communications interface_0 (SCI_0)

MSTPB7

R/W

2C bus interface 2_1 (IIC2_1)

MSTPB6

R/W

2C bus interface 2_0 (IIC2_0)

MSTPB5

R/W

User break controller (UBC)

MSTPB4

MSTPB3

MSTPB2

MSTPB1

MSTPB0

R/W

Reserved

These bits are always read as 1. The write value should

always be 1.
