Section 28 Power-Down Modes

Rev. 2.00 Sep. 24, 2008 Page 1252 of 1468

REJ09B0412-0200

Bit

Bit Name

Initial

Value

R/W

Module

DLVDIE*

R/W

LVD Interrupt Enable

Enables or disables exit from deep software standby mode

by voltage monitoring interrupt signal.

0: Disables exit from deep software standby mode by voltage

monitoring interrupt signal.

1: Enables exit from deep software standby mode by voltage

monitoring interrupt signal.

DIRQ3E

R/W

IRQ3 Interrupt Enable

Enables or disables exit from deep software standby mode

by IRQ3-A.

0: Disables exit from deep software standby mode by

IRQ3-A.

1: Enables exit from deep software standby mode by

IRQ3-A.

DIRQ2E

R/W

IRQ2 Interrupt Enable

Enables or disables exit from deep software standby mode

by IRQ2-A.

0: Disables exit from deep software standby mode by

IRQ2-A.

1: Enables exit from deep software standby mode by

IRQ2-A.

DIRQ1E

R/W

IRQ1 Interrupt Enable

Enables or disables exit from deep software standby mode

by IRQ1-A.

0: Disables exit from deep software standby mode by

IRQ1-A.

1: Enables exit from deep software standby mode by

IRQ1-A.

DIRQ0E

R/W

IRQ0 Interrupt Enable

Enables or disables exit from deep software standby mode

by IRQ0-A.

0: Disables exit from deep software standby mode by

IRQ0-A.

1: Enables exit from deep software standby mode by

IRQ0-A.

Note:

Supported only by the H8SX/1668M Group
