151 / 182 page  151 4173E–USB–09/07 AT89C5132 Table 33. ADDH Register ADDH (S:F5h Read Only) – ADC Data High Byte Register Reset Value = 0000 0000b Table 34. ADDL Register ADDL (S:F4h Read Only) – ADC Data Low Byte Register Reset Value = 0000 0000b 7 6 5 4 3 2 1 0 ADAT9 ADAT8 ADAT7 ADAT6 ADAT5 ADAT4 ADAT3 ADAT2 Bit Number Bit Mnemonic Description 7 - 0 ADAT9:2 ADC Data 8 Most Significant Bits of the 10-bit ADC data. 7 6 5 4 3 2 1 0 - - - - - - ADAT1 ADAT0 Bit Number Bit Mnemonic Description 7 - 2 - Reserved The value read from these bits is always 0. Do not set these bits. 1 - 0 ADAT1:0 ADC Data 2 Least Significant Bits of the 10-bit ADC data. |
|
