1292 / 1504 page ![]() Section 28 Power-Down Modes Rev. 2.00 Sep. 24, 2008 Page 1260 of 1468 REJ09B0412-0200 28.4 Module Stop State Module stop functionality can be set for individual on-chip peripheral modules. When the corresponding MSTP bit in MSTPCRA, MSTPCRB, or MSTPCRC is set to 1, module operation stops at the end of the bus cycle and a transition is made to a module stop state. The CPU continues operating independently. When the corresponding MSTP bit is cleared to 0, a module stop state is cleared and the module starts operating at the end of the bus cycle. In a module stop state, the internal states of modules other than the SCI are retained. After the reset state is cleared, all modules other than the EXDMAC, DMAC, and DTC and on- chip RAM are placed in a module stop state. The registers of the module for which the module stop state is selected cannot be read from or written to. 28.5 Sleep Mode 28.5.1 Entry to Sleep Mode When the SLEEP instruction is executed when the SSBY bit in SBYCR is 0, the CPU enters sleep mode. In sleep mode, CPU operation stops but the contents of the CPU's internal registers are retained. Other peripheral functions do not stop. 28.5.2 Exit from Sleep Mode Sleep mode is exited by any interrupt, signals on the RES or STBY pin, and a reset caused by a watchdog timer overflow, a voltage monitoring reset*, or a power-on reset*. • Exit from sleep mode by interrupt When an interrupt occurs, sleep mode is exited and interrupt exception processing starts. Sleep mode is not exited if the interrupt is disabled, or interrupts other than NMI are masked by the CPU. • Exit from sleep mode by RES pin Setting the RES pin level low selects the reset state. After the stipulated reset input duration, driving the RES pin high makes the CPU start the reset exception processing. • Exit from sleep mode by STBY pin When the STBY pin level is driven low, a transition is made to hardware standby mode. |
|
