44 / 48 page  ADRF6755 Data Sheet Rev. B | Page 44 of 48 BILL OF MATERIALS Table 29. Bill of Materials Qty Reference Designator Description Manufacturer Part Number 1 DUT ADRF6755, 56-lead 8 mm × 8 mm LFCSP Analog Devices ADRF6755ACPZ 1 Y2 Crystal Oscillator, 80 MHz Jauch O 80.0-JO75-B-3.3-2-T1 1 CONN1 Connector, FX8-120S-SV(21) Hirose FEC 1324660 2 C1, C21 Capacitor, 10 µF, 25 V, tantalum, TAJ-C AVX FEC 197518 12 C4, C6, C8, C10, C12, C14, C16, C18, C19, C48, C53, C55 Capacitor, 10 pF, 50 V, ceramic, C0G, 0402 Murata FEC 8819564 14 C5, C7, C9, C11, C13, C15, C17, C22, C47, C49 to C52, C54 Capacitor, 100 nF, 25 V, X7R, ceramic, 0603 AVX FEC 317287 1 C20 Capacitor, 220 µF, 6.3 V, tantalum, Case Size C AVX FEC 197087 4 C30 to C33 Capacitor spacing, 0402 (do not install) 1 C26 Capacitor, 1.2 nF, 50 V, C0G, ceramic, 0603 Kemet FEC 1813421 1 C24 Capacitor, 47 nF, 50 V, C0G, ceramic, 1206 Murata FEC 8820201 2 C23, C25 Capacitor, 560 pF, 50 V, NP0, ceramic, 0603 Murata FEC 1828912 2 C38, C39 Capacitor, 1 nF, 50 V, C0G, ceramic, 0402 Murata FEC 8819556 3 C44, C46, C57 Capacitor, 100 pF, 50 V, C0G, ceramic, 0402 Murata FEC 8819572 11 J2 to J5, J7, J10 to J12, J14, J15, TXDIS SMA end launch connector Johnson/Emerson 142-0701-851 2 J18, J21 Jumper, 3-pin + shunt Harwin FEC 148533 and FEC 150411 2 L1, L2 Inductor, 20 nH, 0402, 5% TE Connectivity FEC 1265424 2 L3, L4 Inductor, 10 µH, 0805, LQM series Vishay FEC 1653752 5 R6 to R9, R36 Resistor, 0 Ω, 1/16 W, 1%, 0402 Multicomp FEC 1357983 2 R10, R11 Resistor, 0402, spacing (do not install) 1 R13 Resistor, 4.7 kΩ, 1/10 W, 1%, 0603 Bourns FEC 2008358 2 R12, R16 Resistor, 160 Ω, 1/16 W, 1%, 0603 Multicomp FEC 9330658 1 R15 Resistor, 150 Ω, 1/16 W, 1%, 0603 Multicomp FEC 9330593 2 R62 Resistor, 0603, spacing (do not install) 3 R35, R44, R45 Resistor, 51 Ω, 1/16 W, 5%, 0402 Bourns FEC 2008358 4 R48 to R51 Resistor, 330 Ω, 1/10 W, 5%, 0805 Vishay FEC 1739223 3 R59 to R61 Resistor, 100 Ω, 1/10 W, 5%, 0805 Vishay FEC 1652907 2 R63, R64 Resistor, 100 kΩ, 1/16 W, 1%, 0603 Multicomp FEC 9330402 1 D1 LED, red, 0805, 1.8 V, low current Rohm FEC 1685056 1 U1 IC 24LC32A-I/MS EEPROM MSOP-8 Microchip FEC 133-4660 |
|
