31 / 51 page ![]() IR3447 31 www.irf.com © 2013 International Rectifier July 17, 2013 to the RSA, β = 1. Please refer to the Remote Sensing Amplifier section) Lo = 0.215 µH Co = 10 x 47µF, ESR≈3mΩ each It must be noted here that the value of the capacitance used in the compensator design must be the small signal value. For instance, the small signal capacitance of the 47µF capacitor used in this design is 25.7µF at 1.2 V DC bias and 600 kHz frequency. It is this value that must be used for all computations related to the compensation. The small signal value may be obtained from the manufacturer’s datasheets, design tools or SPICE models. Alternatively, they may also be inferred from measuring the power stage transfer function of the converter and measuring the double pole frequency FLC and using equation (20) to compute the small signal Co. These result to: FLC = 21.4 kHz FESR = 2.06 MHz Fs/2 = 300 kHz Select crossover frequency F0=100 kHz Since FLC<F0<Fs/2<FESR, Type III is selected to place the pole and zeros. Detailed calculation of compensation Type III: Desired Phase Margin Θ = 70° sin 1 sin 1 2 o Z F F 17.6 kHz sin 1 sin 1 2 o P F F 567.1 kHz Select: 2 1 5 . 0 Z Z F F 8.8 kHz and s P F F 5 . 0 3 300 kHz Select C4 = 2.2nF. Calculate R3, C3 and C2: in osc o o o V C V C L F R 4 3 2 ; R3 = 2.37 kΩ, Select: R3 = 1.91 kΩ 3 1 3 2 1 R F C Z ; C3 = 7.5 nF, Select: C3 = 8.2 nF 3 3 2 2 1 R F C P ; C2 = 221 pF, Select: C2 = 160 pF Calculate R4, R5 and R6: 2 4 4 2 1 P F C R ; R4 = 127.6 Ω, Select R4 = 127 Ω 2 4 5 2 1 Z F C R ; R5 = 4.11 kΩ, Select R5 = 4.22 kΩ 5 6 R V V V R ref o ref ; R6 = 4.11 kΩ, Select R6 = 4.22 kΩ If (β x Vo) equals Vref, R6 is not used. Setting the Power Good Threshold In this design IR3447, the PGood outer limits are set at 95% and 120% of VREF. PGood signal is asserted 1.3ms after Vsns voltage reaches 0.95*0.6V=0.57V (Figure 28) . As long as the Vsns voltage is between the threshold ranges, Enable is high, and no fault happens, the PGood remains high. The following formula can be used to set the PGood threshold. Vout (PGood_TH) can be taken as 95% of Vout. Choose Rsns1=4.22 KΩ. |
|
