5 / 66 page  Data Sheet ADAR4002 SPECIFICATIONS analog.com Rev. A | 5 of 66 Table 1. Specifications (Continued) Parameter Test Conditions/Comments Min Typ Max Unit RMS Time Delay Error4 Time Delay Range 0 500 MHz TDU Sweep 0 to TDU Sweep 127 22.59 ps 2 GHz TDU Sweep 0 to TDU Sweep 127 2.58 ps 10 GHz TDU Sweep 0 to TDU Sweep 127 13.68 ps 18 GHz TDU Sweep 0 to TDU Sweep 127 4.83 ps Time Delay Range 1 500 MHz TDU Sweep 0 to TDU Sweep 127 14.56 ps 2 GHz TDU Sweep 0 to TDU Sweep 127 1.15 ps 10 GHz TDU Sweep 0 to TDU Sweep 127 7.1 ps 18 GHz TDU Sweep 0 to TDU Sweep 127 4.04 ps RMS Time Delay Variation Time Delay Range 0 500 MHz DSA sweep, 0 dB to 15.5 dB 2.62 ps DSA sweep, 0 dB to 31.5 dB 3.52 ps 2 GHz DSA sweep, 0 dB to 15.5 dB 0.84 ps DSA sweep, 0 dB to 31.5 dB 4.1 ps 10 GHz DSA sweep, 0 dB to 15.5 dB 0.65 ps DSA sweep, 0 dB to 31.5 dB 2.95 ps 18 GHz DSA sweep, 0 dB to 15.5 dB 0.89 ps DSA sweep, 0 dB to 31.5 dB 8.97 ps Time Delay Range 1 500 MHz DSA sweep, 0 dB to 15.5 dB 2.41 ps DSA sweep, 0 dB to 31.5 dB 3.34 ps 2 GHz DSA sweep, 0 dB to 15.5 dB 0.94 ps DSA sweep, 0 dB to 31.5 dB 4.28 ps 10 GHz DSA sweep, 0 dB to 15.5 dB 0.57 ps DSA sweep, 0 dB to 31.5 dB 3.4 ps 18 GHz DSA sweep, 0 dB to 15.5 dB 0.57 ps DSA sweep, 0 dB to 31.5 dB 4.46 ps Noise Figure5 Time Delay Range 0 500 MHz 11.4 dB 2 GHz 12.77 dB 10 GHz 21.2 dB 18 GHz 32 dB Time Delay Range 1 500 MHz 9.1 dB 2 GHz 10.4 dB 10 GHz 16.6 dB 18 GHz 24.4 dB Input Return Loss RF1 Time Delay Range 0 500 MHz −13.5 dB 2 GHz −20.2 dB 10 GHz −10.4 dB 18 GHz −14.7 dB Time Delay Range 1 500 MHz −13.3 dB 2 GHz −20.7 dB 10 GHz −10.1 dB 18 GHz −14.1 dB |
|
