53 / 66 page ![]() Data Sheet ADAR4002 REGISTER MAP analog.com Rev. A | 53 of 66 Table 14. ADAR4002 Register Summary (Continued) Addr Name Bits Bit Name Description Reset Access 0x41 DSA16 [7:2] FIRSTRANK_DSA16 6-Bit Attenuation Control. Default = 0x3F, maximum attenuation. 0x3F R/W 1 RESERVED Reserved. 0x0 R 0 DATA_LOAD Load Signal for Second Rank of Registers. This bit auto clears after being set. 0x0 R/W 0x42 TD17 7 FR_TDRANGE17 Time Delay Range. 0 = Range 0, 508 ps, and 1 = Range 1, 254 ps. 0x0 R/W [6:0] FIRSTRANK_TIMEDELAY17 7-Bit Time Delay Control. Default = 0x00, minimum time delay. 0x0 R/W 0x43 DSA17 [7:2] FIRSTRANK_DSA17 6-Bit Attenuation Control. Default = 0x3F, maximum attenuation. 0x3F R/W 1 RESERVED Reserved. 0x0 R 0 DATA_LOAD Load Signal for Second Rank of Registers. This bit auto clears after being set. 0x0 R/W 0x44 TD18 7 FR_TDRANGE18 Time Delay Range. 0 = Range 0, 508 ps, and 1 = Range 1, 254 ps. 0x0 R/W [6:0] FIRSTRANK_TIMEDELAY18 7-Bit Time Delay Control. Default = 0x00, minimum time delay. 0x0 R/W 0x45 DSA18 [7:2] FIRSTRANK_DSA18 6-Bit Attenuation Control. Default = 0x3F, maximum attenuation. 0x3F R/W 1 RESERVED Reserved. 0x0 R 0 DATA_LOAD Load Signal for Second Rank of Registers. This bit auto clears after being set. 0x0 R/W 0x46 TD19 7 FR_TDRANGE19 Time Delay Range. 0 = Range 0, 508 ps, and 1 = Range 1, 254 ps. 0x0 R/W [6:0] FIRSTRANK_TIMEDELAY19 7-Bit Time Delay Control. Default = 0x00, minimum time delay. 0x0 R/W 0x47 DSA19 [7:2] FIRSTRANK_DSA19 6-Bit Attenuation Control. Default = 0x3F, maximum attenuation. 0x3F R/W 1 RESERVED Reserved. 0x0 R 0 DATA_LOAD Load Signal for Second Rank of Registers. This bit auto clears after being set. 0x0 R/W 0x48 TD20 7 FR_TDRANGE20 Time Delay Range. 0 = Range 0, 508 ps, and 1 = Range 1, 254 ps. 0x0 R/W [6:0] FIRSTRANK_TIMEDELAY20 7-Bit Time Delay Control. Default = 0x00, minimum time delay. 0x0 R/W 0x49 DSA20 [7:2] FIRSTRANK_DSA20 6-Bit Attenuation Control. Default = 0x3F, maximum attenuation. 0x3F R/W 1 RESERVED Reserved. 0x0 R 0 DATA_LOAD Load Signal for Second Rank of Registers. This bit auto clears after being set. 0x0 R/W 0x4A TD21 7 FR_TDRANGE21 Time Delay Range. 0 = Range 0, 508 ps, and 1 = Range 1, 254 ps. 0x0 R/W [6:0] FIRSTRANK_TIMEDELAY21 7-Bit Time Delay Control. Default = 0x00, minimum time delay. 0x0 R/W 0x4B DSA21 [7:2] FIRSTRANK_DSA21 6-Bit Attenuation Control. Default = 0x3F, maximum attenuation. 0x3F R/W 1 RESERVED Reserved. 0x0 R 0 DATA_LOAD Load Signal for Second Rank of Registers. This bit auto clears after being set. 0x0 R/W |
|
