Data Sheet

ADAR4002

analog.com

Rev. A | 56 of 66

Table 14. ADAR4002 Register Summary (Continued)

Addr

Name

Bits Bit Name

Description

Reset Access

[1:0] FIRSTRANK_DSA01, Bits[5:4]

6-Bit Attenuation Control. Default = 0x3F, maximum

attenuation.

0x3

R/W

0x63

STREAMWRITE03

[7:4] FIRSTRANK_DSA01, Bits[3:0]

6-Bit Attenuation Control. Default = 0x3F, maximum

attenuation.

0xF

R/W

FR_TDRANGE02

Time Delay Range. 0 = Range 0, 508 ps, and 1 = Range 1,

254 ps.

0x0

R/W

[2:0] FIRSTRANK_TIMEDELAY02, Bits[6:4] 7-Bit Time Delay Control. Default = 0x00, minimum time

delay.

0x0

R/W

0x64

STREAMWRITE04

[7:4] FIRSTRANK_TIMEDELAY02, Bits[3:0] 7-Bit Time Delay Control. Default = 0x00, minimum time

delay.

0x0

R/W

[3:0] FIRSTRANK_DSA02, Bits[5:2]

6-Bit Attenuation Control. Default = 0x3F, maximum

attenuation.

0xF

R/W

0x65

STREAMWRITE05

[7:6] FIRSTRANK_DSA02, Bits[1:0]

6-Bit Attenuation Control. Default = 0x3F, maximum

attenuation.

0x3

R/W

FR_TDRANGE03

Time Delay Range. 0 = Range 0, 508 ps, and 1 = Range 1,

254 ps.

0x0

R/W

[4:0] FIRSTRANK_TIMEDELAY03, Bits[6:2] 7-Bit Time Delay Control. Default = 0x00, minimum time

delay.

0x0

R/W

0x66

STREAMWRITE06

[7:6] FIRSTRANK_TIMEDELAY03, Bits[1:0] 7-Bit Time Delay Control. Default = 0x00, minimum time

delay.

0x0

R/W

[5:0] FIRSTRANK_DSA03

6-Bit Attenuation Control. Default = 0x3F, maximum

attenuation.

0x3F

R/W

0x67

STREAMWRITE07

FR_TDRANGE04

Time Delay Range. 0 = Range 0, 508 ps, and 1 = Range 1,

254 ps.

0x0

R/W

[6:0] FIRSTRANK_TIMEDELAY04

7-Bit Time Delay Control. Default = 0x00, minimum time

delay.

0x0

R/W

0x68

STREAMWRITE08

[7:2] FIRSTRANK_DSA04

6-Bit Attenuation Control. Default = 0x3F, maximum

attenuation.

0x3F

R/W

FR_TDRANGE05

Time Delay Range. 0 = Range 0, 508 ps, and 1 = Range 1,

254 ps.

0x0

R/W

FIRSTRANK_TIMEDELAY05, Bit 6

7-Bit Time Delay Control. Default = 0x00, minimum time

delay.

0x0

R/W

0x69

STREAMWRITE09

[7:2] FIRSTRANK_TIMEDELAY05, Bits[5:0] 7-Bit Time Delay Control. Default = 0x00, minimum time

delay.

0x0

R/W

[1:0] FIRSTRANK_DSA05, Bits[5:4]

6-Bit Attenuation Control. Default = 0x3F, maximum

attenuation.

0x3

R/W

0x6A

STREAMWRITE0A

[7:4] FIRSTRANK_DSA05, Bits[3:0]

6-Bit Attenuation Control. Default = 0x3F, maximum

attenuation.

0xF

R/W

FR_TDRANGE06

Time Delay Range. 0 = Range 0, 508 ps, and 1 = Range 1,

254 ps.

0x0

R/W

[2:0] FIRSTRANK_TIMEDELAY06, Bits[6:4] 7-Bit Time Delay Control. Default = 0x00, minimum time

delay.

0x0

R/W

0x6B

STREAMWRITE0B

[7:4] FIRSTRANK_TIMEDELAY06, Bits[3:0] 7-Bit Time Delay Control. Default = 0x00, minimum time

delay.

0x0

R/W

[3:0] FIRSTRANK_DSA06, Bits[5:2]

6-Bit Attenuation Control. Default = 0x3F, maximum

attenuation.

0xF

R/W

0x6C

STREAMWRITE0C

[7:6] FIRSTRANK_DSA06, Bits[1:0]

6-Bit Attenuation Control. Default = 0x3F, maximum

attenuation.

0x3

R/W

FR_TDRANGE07

Time Delay Range. 0 = Range 0, 508 ps, and 1 = Range 1,

254 ps.

0x0

R/W

[4:0] FIRSTRANK_TIMEDELAY07, Bits[6:2] 7-Bit Time Delay Control. Default = 0x00, minimum time

delay.

0x0

R/W
