MB9BF412R Datasheet(PDF) 84 Page - SPANSION |
|
|
|||||||||||||||||||||||||||||
MB9BF412R Datasheet(HTML) 84 Page - SPANSION |
|
|
84 / 121 page  D a t a S h e e t March 11, 2015, MB9B410R-DS706-00026-3v0-E 81 CONFIDENTIAL ・ Multiplexed Bus Access Asynchronous SRAM Mode (VCC = 2.7V to 5.5V, VSS = 0V, TA = - 40°C to + 85°C) Parameter Symbol Pin name Conditions Value Unit Min Max Multiplexed address delay time tALE-CHMADV MALE MADATA[15:0] VCC ≥ 4.5 V 0 10 ns VCC < 4.5 V 20 Multiplexed address hold time tCHMADH VCC ≥ 4.5 V MCLK×n+0 MCLK×n+10 ns VCC < 4.5 V MCLK×n+0 MCLK×n+20 Note: When the external load capacitance = 30 pF. (m = 0 to 15, n = 1 to 16) MCLK MCSX[7:0] MALE MOEX MWEX MADATA[15:0] MAD [24:0] MDQM [1:0] |
|
