D a t a S h e e t
82
MB9B410R-DS706-00026-3v0-E, March 11, 2015
CONFIDENTIAL
・ Multiplexed Bus Access Synchronous SRAM Mode
(VCC = 2.7V to 5.5V, VSS = 0V, TA = - 40°C to + 85°C)
Parameter
Symbol
Pin name
Conditions
Value
Unit Remarks
Min
Max
MALE delay time
tCHAL
MCLK
ALE
VCC ≥ 4.5 V
1
9
ns
VCC < 4.5 V
12
ns
tCHAH
VCC ≥ 4.5 V
1
9
ns
VCC < 4.5 V
12
ns
MCLK ↑ →
Multiplexed
Address delay time
tCHMADV
MCLK
MADATA[15:0]
VCC ≥ 4.5 V
1
tOD
ns
VCC < 4.5 V
MCLK ↑ →
Multiplexed
Data output time
tCHMADX
VCC ≥ 4.5 V
1
tOD
ns
VCC < 4.5 V
Note: When the external load capacitance = 30 pF.
MCLK
MCSX[7:0]
MALE
MOEX
MWEX
MADATA[15:0]
MAD [24:0]
MDQM [1:0]
