(13) ETM timing
(VCC = 2.7V to 5.5V, VSS = 0V, TA = - 40°C to + 85°C)
Parameter
Symbol
Pin name
Conditions
Value
Unit
Remarks
Min
Max
Data hold
tETMH
TRACECLK
TRACED[3:0]
VCC ≥ 4.5 V
2
9
ns
VCC < 4.5 V
2
15
TRACECLK
frequency
1/ tTRACE
TRACECLK
VCC ≥ 4.5 V
-
50
MHz
VCC < 4.5 V
-
32
MHz
TRACECLK
cycle time
tTRACE
VCC ≥ 4.5 V
20
-
ns
VCC < 4.5 V
31.25
-
ns
Note: When the external load capacitance = 30 pF.
HCLK
TRACECLK
TRACED[3:0]
