83/90

STA310

PCMV_STATUS2

Address : 0x78

Type: RW

Reset Value: UND

Description:

This register sets the dynamic range compression

from the first access unit. For the hexadecimal value

0x80, dynamic range control is not set. For all other

values, the dynamic range control is

(24.082 - 6.0206 * X - 0.2007 * Y)dB, where

X = dynamic_range_control[7..5] and

Y = dynamic_range_control[4..0].

LPCMV_CH_ASSIGN

Channel assignment

Address: 0xA8

Type: R/W

Software Reset: NC

Hardware Reset: UND

Description:

PCMV_MULTI_CHS

Multi channels

Address: 0xA9

Type: R/W

Software Reset: NC

Hardware Reset: UND

Description:

9.24 MLP registers

MLP_CRC

CRC check

Address: 0x6C

Type: R/W

Software Reset: NC

Hardware Reset: UND

Description:

This register controls the four different CRCs in MLP.

If the check is false, an error is returned (error num-

bers 80-83 in register and the outputs of all 6 chan-

nels are muted

MLP_DOWNMIX

Downmix

Address: 0x6F

Type: R/W

Software Reset: NC

Hardware Reset: UND

76543210

Dyn_Range_Control

65432

Reserved

Value

Description

Value

(decimal)

This register configures the audio channels:

See "DVD Specifications for Read-Only

Disc", Part 4 AUDIO SPECIFICATIONS,

Version 1.0, March 1999, Table C.1-2.

7654321

Reserved

Value

Description

Value (decimal)

This register configures the multi

channel structure for the output

channels:

0: Stereo

1: Multi channels

765

reserved

SU_P MA_S MS_C

RH_C

Bitfield

Description

RH_C

1: Check of ’Restart_Header_CRC’ enable

MS_C

1: Check of ’Major_Sync_CRC’ enable

MA_C

1: Check of ’Max_Shift’ enable

SU_P

1: Check of ’Substream_Parity’ enable

7654321

DWNMIX[7:0]
