STA310
14/90
Table 3. Decode Mode. Play and Mute commands effects
Note: 1. It is not possible to change configuration registers in this state. It is necessary to soft reset the chip before. Only the following reg-
isters can be changed “on-the-fly”: PCM_SCALE, BAL_LR, BAL_SUR, OCFG, DOWNMIX registers.
4.4 Data input interface description.
Figure 6. Block Diagram of Data Flow
Play
Mute
Clock State
PCM Output
Decoding
0
0
Not running
0
No
0
1
Running
0
No
1
0
Running
Decoded Samples
Yes
1
1
Running
0
Yes
