STA310 datasheet(42/90 Pages) STMICROELECTRONICS

42 / 90 page

STA310

42/90

PLLData

Address: 0x11

Type: R/W

Software Reset: NA

Hardware Reset: 0

Description:

Data that must be written (has been read) at (from)

the address specified by PLL_ADD.

PLL_CMD

PLL Command

Address: 0x1D

Type: R/W

Software Reset: NA

Hardware Reset: 0

Description:

PLL_ADD

PLL Address

Address: 0x12

Type: R/W

Software Reset: NA

Hardware Reset: 0

Description:

ENA_AU_FRACPLL

Audio PLL Enable

Address: 0xB5

Type: R/W

Software Reset: 1

Hardware Reset: 0

Description:

This register is used to enable the audio PLL of the

STA310. This register must be always set to “1” after

either a soft or hardware reset.

AU_PLL_FRACL_192

Frac Low Coefficient

Address: 0xB6

321

7654

AUPLLCTL

SYSPLLCTL

RWCTL[1:0]

Bitfield

Description

RWCTL [1:0]

Configure PCMCLK source and

direction.

00: No action is performed on the

configuration registers of the level 1

01: Read action of the configuration

registers. During this phase, the

content of a selectable (by PLL_ADD)

PLL_DATA register.

10: Write action of the configuration

registers. During .this phase, the

content of a selectable (by PLL_ADD)

PLL_DATA register.

11: Forbidden

SYSPLLCTL

System PLL coefficients transfert

0: No Transfer

1: Transfer the data between the level 1

and the level 2 for the system PLL

AUPLLCTL

Audio PLL coefficient transfert

0: No Transfer

1: Transfer the data between the level 1

and the level 2 for the audio PLL

321

ADDRESS

Value

Address of PLLs configuration registers

Address

2: Disable System PLL

3: System PLL frac Low

4: System PLL frac High

6: System PLL N divider

7: System PLL X divider

8: System PLL M divider

9: System PLL update

10: Disable Audio PLL

11: Audio PLL Frac Low

12: Audio PLL Frac High

14: Audio PLL N divider

15: Audio PLL X divider

16: Audio PLL M divider

17: udio PLL update

765

ENA_PLL

321

FRACL
