background image
5/90
STA310
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS (VDD = 3.3V +/-0.3V; Tamb = 0 to 70°C; Rg = 50 Ω unless otherwise spec-
ified
GENERAL INTERFACE
Note: 1. The leakage currents are generally very small, <1nA. The value given here, 1
µA, is a maximum that can occur after an Electrostatic
Stress on the pin.
2. V> Vdd3 for 3.3V buffers.
3. Human Body Model
LVTTL & LVCMOS DC Input Specification 2.7V <Vdd3 <3.6V
Note: 1. Takes into account 200mV voltage drop in both supply lines.
2. X in the source/sink current under worst case conditions and is reflected in the name of the I/O cell according to the drive capability
Symbol
Parameters
Value
Unit
Vdd
2.5V Power Supply Voltage
-0.5 to 3.3
V
2.5V Input or Output Voltage
-0.5 to (Vdd+0.5)
V
Vdd3
3.3V Power Supply Voltage
-0.5 to 4
V
3.3V Input or Output Voltage
-0.5 to (Vdd+0.5)
V
DC OPERATING CONDITIONS
Symbol
Parameters
Value
Unit
Vcc
Power Supply Voltage
2.5
V
Tj
Operating Junction Temperature
-20 to 125
°C
Symbol
Parameters
Conditions
Min
Typ
Max
Unit
Note
Iil
Low level input current without
pull-up device
Vi = 0V
1
µA
1
Iih
High level input current without
pull-down device
Vi = Vdd
1
µA1
Ioz
Tri-state output leakage without
pull-up/down device
Vi = 0V or Vdd
1
µA1
Ilatchup
I/O Latch-up current
V<0V, V>Vdd
200
mA
2
Vesd
Electrostatic protection
Leakage <1
µA
2000
V
3
Symbol
Parameters
Conditions
Min
Typ
Max
Unit
Note
Vil
Low level input voltage
0.8
V
1
Vih
High level input voltage
2.0
V
1
Vilhyst
Low level threshold input falling
0.8
1.35
V
1
Vihhyst
High level threshold input rising
1.3
2.0
V
1
Vhyst
Schmitt trigger hysteresis
0.3
0.8
V
1
