41 / 112 page  Document Number: 002-05615 Rev. *D Page 41 of 112 MB9B410R Series Type Circuit Remarks C − Open drain output − CMOS level hysteresis input D It is possible to select the sub oscillation / GPIO function When the sub oscillation is selected. − Oscillation feedback resistor: Approximately 5 MΩ − With Standby mode control When the GPIO is selected. − CMOS level output. − CMOS level hysteresis input − With pull-up resistor control − With standby mode control − Pull-up resistor: Approximately 50 kΩ − IOH = -4 mA, IOL= 4 mA N-ch P-ch P-ch N-ch R R P-ch P-ch N-ch X0A X1A Pull-up resistor Feedback resistor Pull-up resistor Digital input Digital output Digital output Digital output Pull-up resistor control Digital input Standby mode Control Clock input Standby mode Control Digital input Standby mode Control Digital output Digital output Pull-up resistor control |
|
