89 / 112 page ![]() Document Number: 002-05615 Rev. *D Page 89 of 112 MB9B410R Series 12.4.11 External Input Timing (VCC = 2.7V to 5.5V, VSS = 0V, TA = - 40°C to + 85°C) Parameter Symbol Pin name Conditions Value Unit Remarks Min Max Input pulse width tINH, tINL ADTG - 2tCYCP* - ns A/D converter trigger input FRCKx Free-run timer input clock ICxx Input capture DTTIxX - 2tCYCP* - ns Wave form generator INTxx, NMIX Except Timer mode, Stop mode 2tCYCP + 100* - ns External interrupt NMI Timer mode, Stop mode 500*2 - ns *: tCYCP indicates the APB bus clock cycle time. About the APB bus number which A/D converter, Multi-function Timer, External interrupt is connected to, see 8 Block Diagram in this data sheet. |
|
