94 / 112 page ![]() Document Number: 002-05615 Rev. *D Page 94 of 112 MB9B410R Series 12.4.15 JTAG Timing (VCC = 2.7V to 5.5V, VSS = 0V, TA = - 40°C to + 85°C) Parameter Symbol Pin name Conditions Value Unit Remarks Min Max TMS, TDI setup time tJTAGS TCK, TMS, TDI VCC ≥ 4.5 V 15 - ns VCC < 4.5 V TMS, TDI hold time tJTAGH TCK, TMS, TDI VCC ≥ 4.5 V 15 - ns VCC < 4.5 V TDO delay time tJTAGD TCK, TDO VCC ≥ 4.5 V - 25 ns VCC < 4.5 V - 45 Note: − When the external load capacitance = 30 pF. TCK TMS/TDI TDO |
|
