54 / 112 page  Document Number: 002-05615 Rev. *D Page 54 of 112 MB9B410R Series Memory Map (3) See "MB9B510R/410R/310R/110R Series Flash programming Manual" for sector structure of Flash. MB9BF414N/R 0x200E_0000 Reserved 0x200C_8000 0x200C_0000 SA0-3 (8KBx4) 0x2000_4000 Reserved 0x2000_0000 SRAM1 16Kbyte 0x1FFF_C000 SRAM0 16Kbyte 0x0010_2000 Reserved 0x0010_1000 CR trimming 0x0010_0000 Security 0x0004_0000 Reserved 0x0000_0000 SA10-11 (64KBx2) SA8-9 (48KBx2) SA4-7 (8KBx4) MB9BF412N/R 0x200E_0000 Reserved 0x200C_8000 0x200C_0000 SA0-3 (8KBx4) 0x2000_2000 Reserved 0x2000_0000 SRAM1 8Kbyte 0x1FFF_E000 SRAM0 8Kbyte 0x0010_2000 Reserved 0x0010_1000 CR trimming 0x0010_0000 Security 0x0002_0000 Reserved 0x0000_0000 SA8-9 (48KBx2) SA4-7 (8KBx4) |
|
