26 / 112 page  Document Number: 002-05615 Rev. *D Page 26 of 112 MB9B410R Series Module Pin name Function Pin No LQFP- 100 FBGA- 112 LQFP- 120 QFP- 100 Base Timer 4 TIOA4_0 Base timer ch.4 TIOA pin 31 H5 36 9 TIOA4_1 23 H3 28 1 TIOA4_2 - - 51 - TIOB4_0 Base timer ch.4 TIOB pin 44 J7 49 22 TIOB4_1 13 F1 18 91 TIOB4_2 - - 52 - Base Timer 5 TIOA5_0 Base timer ch.5 TIOA pin 32 L6 37 10 TIOA5_1 24 J2 29 2 TIOA5_2 82 C8 97 60 TIOB5_0 Base timer ch.5 TIOB pin 45 K8 50 23 TIOB5_1 14 F2 19 92 TIOB5_2 83 D9 98 61 Base Timer 6 TIOA6_0 Base timer ch.6 TIOA pin - - 53 - TIOA6_1 89 B6 104 67 TIOA6_2 - - 82 - TIOB6_0 Base timer ch.6 TIOB pin - - 54 - TIOB6_1 88 A6 103 66 TIOB6_2 - - 81 - Base Timer 7 TIOA7_0 Base timer ch.7 TIOA pin - - 112 - TIOA7_1 71 D10 86 49 TIOA7_2 - - 109 - TIOB7_0 Base timer ch.7 TIOB pin - - 111 - TIOB7_1 72 E8 87 50 TIOB7_2 - - 108 - CAN 0 TX0_0 CAN interface ch.0 TX output pin - - 51 - TX0_1 13 F1 18 91 TX0_2 94 C5 114 72 RX0_0 CAN interface ch.0 RX output pin - - 52 - RX0_1 14 F2 19 92 RX0_2 93 D6 113 71 CAN 1 TX1_0 CAN interface ch.1 TX output pin - - 84 - TX1_1 - - 12 - TX1_2 54 J8 64 32 RX1_0 CAN interface ch.1 RX output pin - - 85 - RX1_1 - - 11 - RX1_2 53 J10 63 31 Debugger SWCLK Serial wire debug interface clock input pin 78 B9 93 56 SWDIO Serial wire debug interface data input / output pin 80 A8 95 58 SWO Serial wire viewer output pin 81 B8 96 59 TCK JTAG test clock input pin 78 B9 93 56 TDI JTAG test data input pin 79 B11 94 57 TDO JTAG debug data output pin 81 B8 96 59 TMS JTAG test mode state input/output pin 80 A8 95 58 TRACECLK Trace CLK output pin of ETM 86 C7 101 64 TRACED0 Trace data output pin of ETM 82 C8 97 60 TRACED1 83 D9 98 61 TRACED2 84 A7 99 62 TRACED3 85 B7 100 63 TRSTX JTAG test reset Input pin 77 A9 92 55 |
|
