Document Number: 002-05615 Rev. *D

Page

67 of 112

MB9B410R Series

12.4

AC Characteristics

12.4.1

Main Clock Input Characteristics

(VCC = 2.7V to 5.5V, VSS = 0V, TA = - 40°C to + 85°C)

Parameter

Symbol

name

Conditions

Value

Unit

Remarks

Min

Max

Input frequency

fCH

VCC ≥ 4.5 V

MHz

When crystal oscillator is

connected

VCC < 4.5 V

VCC ≥ 4.5 V

MHz

When using external

clock

VCC < 4.5 V

Input clock cycle

tCYLH

VCC ≥ 4.5 V

20.83

250

When using external

clock

VCC < 4.5 V

250

Input clock pulse

width

PWH/tCYLH

PWL/tCYLH

When using external

clock

Input clock rise

time and fall time

tCF,

tCR

When using external

clock

Internal operating

clock*1 frequency

fCM

144

MHz

Master clock

fCC

144

MHz

Base clock (HCLK/FCLK)

fCP0

MHz

APB0 bus clock*2

fCP1

MHz

APB1 bus clock*2

fCP2

MHz

APB2 bus clock*2

Internal operating

clock*1 cycle time

tCYCC

6.94

Base clock (HCLK/FCLK)

tCYCP0

13.8

APB0 bus clock*2

tCYCP1

13.8

APB1 bus clock*2

tCYCP2

13.8

APB2 bus clock*2

*1: For more information about each internal operating clock, see CHAPTER 2-1: Clock in FM3 Family PERIPHERAL MANUAL.

*2: For about each APB bus which each peripheral is connected to, see 8 Block Diagram in this data sheet.
