background image
MB96340 Series
Document Number: 002-04579 Rev. *A
Page 28 of 109
000081H
PPG1 - Timer register
R
000082H
PPG1 - Period setting register
PCSR1
W
000083H
PPG1 - Period setting register
W
000084H
PPG1 - Duty cycle register
PDUT1
W
000085H
PPG1 - Duty cycle register
W
000086H
PPG1 - Control status register Low
PCNL1
PCN1
R/W
000087H
PPG1 - Control status register High
PCNH1
R/W
000088H
PPG2 - Timer register
PTMR2
R
000089H
PPG2 - Timer register
R
00008AH
PPG2 - Period setting register
PCSR2
W
00008BH
PPG2 - Period setting register
W
00008CH
PPG2 - Duty cycle register
PDUT2
W
00008DH
PPG2 - Duty cycle register
W
00008EH
PPG2 - Control status register Low
PCNL2
PCN2
R/W
00008FH
PPG2 - Control status register High
PCNH2
R/W
000090H
PPG3 - Timer register
PTMR3
R
000091H
PPG3 - Timer register
R
000092H
PPG3 - Period setting register
PCSR3
W
000093H
PPG3 - Period setting register
W
000094H
PPG3 - Duty cycle register
PDUT3
W
000095H
PPG3 - Duty cycle register
W
000096H
PPG3 - Control status register Low
PCNL3
PCN3
R/W
000097H
PPG3 - Control status register High
PCNH3
R/W
000098H
PPG7-PPG4 - General Control register 1 Low
GCN1L1
GCN11
R/W
000099H
PPG7-PPG4 - General Control register 1 High
GCN1H1
R/W
00009AH
PPG7-PPG4 - General Control register 2 Low
GCN2L1
GCN21
R/W
00009BH
PPG7-PPG4 - General Control register 2 High
GCN2H1
R/W
00009CH
PPG4 - Timer register
PTMR4
R
00009DH
PPG4 - Timer register
R
00009EH
PPG4 - Period setting register
PCSR4
W
00009FH
PPG4 - Period setting register
W
0000A0H
PPG4 - Duty cycle register
PDUT4
W
Table 4: I/O map MB96(F)34x
Address
Register
Abbreviation
8-bit access
Abbreviation
16-bit access
Access
