MB96F348CWCPMC-GSE2 Datasheet(PDF) 31 Page - Cypress Semiconductor |
|
|
|||||||||||||||||||||||||||||
MB96F348CWCPMC-GSE2 Datasheet(HTML) 31 Page - Cypress Semiconductor |
|
|
31 / 109 page  MB96340 Series Document Number: 002-04579 Rev. *A Page 31 of 109 0000DEH USART3 - Serial Mode Register SMR3 R/W 0000DFH USART3 - Serial Control Register SCR3 R/W 0000E0H USART3 - TX Register TDR3 W 0000E0H USART3 - RX Register RDR3 R 0000E1H USART3 - Serial Status SSR3 R/W 0000E2H USART3 - Control/Com. Register ECCR3 R/W 0000E3H USART3 - Ext. Status Register ESCR3 R/W 0000E4H USART3 - Baud Rate Generator Register Low BGRL3 BGR3 R/W 0000E5H USART3 - Baud Rate Generator Register High BGRH3 R/W 0000E6H USART3 - Extended Serial Interrupt Register ESIR3 R/W 0000E7H-0000EFH Reserved - 0000F0H-0000FFH External Bus area EXTBUS0 R/W 000100H DMA0 - Buffer address pointer low byte BAPL0 R/W 000101H DMA0 - Buffer address pointer middle byte BAPM0 R/W 000102H DMA0 - Buffer address pointer high byte BAPH0 R/W 000103H DMA0 - DMA control register DMACS0 R/W 000104H DMA0 - I/O register address pointer low byte IOAL0 IOA0 R/W 000105H DMA0 - I/O register address pointer high byte IOAH0 R/W 000106H DMA0 - Data counter low byte DCTL0 DCT0 R/W 000107H DMA0 - Data counter high byte DCTH0 R/W 000108H DMA1 - Buffer address pointer low byte BAPL1 R/W 000109H DMA1 - Buffer address pointer middle byte BAPM1 R/W 00010AH DMA1 - Buffer address pointer high byte BAPH1 R/W 00010BH DMA1 - DMA control register DMACS1 R/W 00010CH DMA1 - I/O register address pointer low byte IOAL1 IOA1 R/W 00010DH DMA1 - I/O register address pointer high byte IOAH1 R/W 00010EH DMA1 - Data counter low byte DCTL1 DCT1 R/W 00010FH DMA1 - Data counter high byte DCTH1 R/W 000110H DMA2 - Buffer address pointer low byte BAPL2 R/W 000111H DMA2 - Buffer address pointer middle byte BAPM2 R/W 000112H DMA2 - Buffer address pointer high byte BAPH2 R/W 000113H DMA2 - DMA control register DMACS2 R/W Table 4: I/O map MB96(F)34x Address Register Abbreviation 8-bit access Abbreviation 16-bit access Access |
|
