background image
MB96340 Series
Document Number: 002-04579 Rev. *A
Page 50 of 109
Note: Any write access to reserved addresses in the I/O map should not be performed. A read access to a reserved address results
in reading ‘X’.Registers of resources which are described in this table, but which are not supported by the device, should also be
handled as “Reserved”.
000884H-00088FH
Reserved
-
000890H
CAN1 - New Data 1 Register Low
NEWDT1L1
NEWDT11
R
000891H
CAN1 - New Data 1 Register High
NEWDT1H1
R
000892H
CAN1 - New Data 2 Register Low
NEWDT2L1
NEWDT21
R
000893H
CAN1 - New Data 2 Register High
NEWDT2H1
R
000894H-00089FH
Reserved
-
0008A0H
CAN1 - Interrupt Pending 1 Register Low
INTPND1L1
INTPND11
R
0008A1H
CAN1 - Interrupt Pending 1 Register High
INTPND1H1
R
0008A2H
CAN1 - Interrupt Pending 2 Register Low
INTPND2L1
INTPND21
R
0008A3H
CAN1 - Interrupt Pending 2 Register High
INTPND2H1
R
0008A4H-0008AFH
Reserved
-
0008B0H
CAN1 - Message Valid 1 Register Low
MSGVAL1L1
MSGVAL11
R
0008B1H
CAN1 - Message Valid 1 Register High
MSGVAL1H1
R
0008B2H
CAN1 - Message Valid 2 Register Low
MSGVAL2L1
MSGVAL21
R
0008B3H
CAN1 - Message Valid 2 Register High
MSGVAL2H1
R
0008B4H-0008CDH
Reserved
-
0008CEH
CAN1 - Output enable register
COER1
R/W
0008CFH-0009FFH
Reserved
-
000A00H
DMA - IO address block register 0
IOABK0
R/W
000A01H
DMA - IO address block register 1
IOABK1
R/W
000A02H
DMA - IO address block register 2
IOABK2
R/W
000A03H
DMA - IO address block register 3
IOABK3
R/W
000A04H
DMA - IO address block register 4
IOABK4
R/W
000A05H
DMA - IO address block register 5
IOABK5
R/W
000A06H-000BFFH
Reserved
-
Table 4: I/O map MB96(F)34x
Address
Register
Abbreviation
8-bit access
Abbreviation
16-bit access
Access
