82 / 109 page

MB96340 Series

Document Number: 002-04579 Rev. *A

Page 82 of 109

WRX pulse width

tWLWH

WRX, WRXL,

WRHX

-tCYC  8-

w/o cycle

extension

Valid data output

 WRX 

time

tDVWH

WRX, WRLX,

WRHX, AD[15:0]

-tCYC  25

w/o cycle

extension

WRX

  Data hold time

tWHDX

WRX, WRLX,

WRHX, AD[15:0]

-tCYC/2  20

WRX

  Address valid time

tWHAX

WRX, WRLX,

WRHX, A[23:16]

tCYC/2  20

WRX

  ALE  time

tWHLH

WRX, WRLX,

WRHX, ALE

EBM:ACE=1 and

EACL:STS=1

2tCYC  15

other EBM:ACE and

EACL:STS setting

tCYC  15

WRX

  ECLK  time

tWLCH

WRX, WRLX,

WRHX, ECLK

-tCYC/2  15

CSn

 WRX time

tCSLWL

WRX, WRLX,

WRHX, CSn

EACL:ACE=0

-3tCYC/2  20

EACL:ACE=1

-5tCYC/2  20

WRX

 CSn time

tWHCSH

WRX, WRLX,

WRHX, CSn

tCYC/2  20

(TA  40°C to 125°C, VCC  3.0 to 4.5V, VSS  0.0 V, IOdrive = 5mA, CL = 50pF)

Parameter

Symbol

Condition

Value

Unit

Remarks

Min

Max
