MB96F348CWCPMC-GSE2 datasheet(65/109 Pages) CYPRESS

65 / 109 page

MB96340 Series

Document Number: 002-04579 Rev. *A

Page 65 of 109

Power supply

current in Sleep

modes[1]

ICCSPLL

PLL Sleep mode with CLKS1/2 = 48MHz,

CLKP1/2 = 24MHz

(CLKRC and CLKSC stopped. Core volt-

age at 1.9V)

+25°C

10.5

Flash devices

+125°C

9.7

+25°C

9.5

MB96345/346

+125°C

8.7

11.5

PLL Sleep mode with CLKS1/2 =

CLKP1= 56MHz, CLKP2 = 28MHz

(CLKRC and CLKSC stopped. Core volt-

age at 1.9V)

+25°C

15.5

MB96F346/F347/F348

+125°C

14.8

+25°C

13.5

MB96345/346

+125°C

14.3

PLL Sleep mode with CLKS1/2 = 72MHz,

CLKP1 = 36MHz,

CLKP2 = 18MHz

(CLKRC and CLKSC stopped. Core volt-

age at 1.9V)

+25°C

10.5

MB96F346/F347/F348Y/R/Ayy

+125°C

11.3

14.5

PLL Sleep mode with CLKS1/2 = 80MHz,

CLKP1 = 40MHz,

CLKP2 = 20MHz

(CLKRC and CLKSC stopped. Core volt-

age at 1.9V)

+25°C

TBD

MB96F345

+125°C

TBD

PLL Sleep mode with CLKS1/2 = 96MHz,

CLKP1= 48MHz,

CLKP2 = 24MHz

(CLKRC and CLKSC stopped. Core volt-

age at 1.9V)

+25°C

16.5

MB96F348T/H/CyB/C

+125°C

15.8

+25°C

15.5

MB96345/346

+125°C

14.8

17.5

ICCSMAIN

Main Sleep mode with CLKS1/2 =

CLKP1/2 = 4MHz

(CLKPLL, CLKSC and CLKRC stopped)

+25°C

1.5

1.8

Flash devices

+125°C

4.5

+25°C

1.5

1.8

MB96345/346

+125°C

3.8

(TA = -40°C to 125°C, VCC = AVCC = 3.0V to 5.5V, VSS = AVSS = 0V)

Parameter

Symbol

Condition (at TA)

Value

Remarks

Typ

Max

Unit
