MB96F348CWCPMC-GSE2 Datasheet(PDF) 58 Page - Cypress Semiconductor |
|
|
|||||||||||||||||||||||||||||
MB96F348CWCPMC-GSE2 Datasheet(HTML) 58 Page - Cypress Semiconductor |
|
|
58 / 109 page  MB96340 Series Document Number: 002-04579 Rev. *A Page 58 of 109 14. Electrical Characteristics 14.1 Absolute Maximum Ratings Parameter Symbol Rating Unit Remarks Min Max Power supply voltage VCC VSS - 0.3 VSS + 6.0 V AVCC VSS - 0.3 VSS + 6.0 V VCC = AVCC [1] AD Converter voltage references AVRH, AVRL VSS - 0.3 VSS + 6.0 V AVCC AVRH, AVCC AVRL, AVRH AVRL, AVRL AVSS Input voltage VI VSS - 0.3 VSS + 6.0 V VI VCC + 0.3V [2] Output voltage VO VSS - 0.3 VSS + 6.0 V VO VCC + 0.3V [2] Maximum Clamp Current ICLAMP -4.0 +4.0 mA Applicable to general purposeI/O pins [3] Total Maximum Clamp Current |ICLAMP| -40 mA Applicable to general purposeI/O pins [3] “L” level maximum output current IOL1 - 15 mA Normal outputs with driving strength set to 5mA “L” level average output current IOLAV1 - 5 mA Normal outputs with driving strength set to 5mA “L” level maximum overall output current IOL1 - 100 mA Normal outputs “L” level average overall output current IOLAV1 - 50 mA Normal outputs ”H” level maximum output current IOH1 - -15 mA Normal outputs with driving strength set to 5mA ”H” level average output current IOHAV1 - -5 mA Normal outputs with driving strength set to 5mA ”H” level maximum overall output current IOH1 - -100 mA Normal outputs ”H” level average overall output current IOHAV1 - -50 mA Normal outputs Permitted Power dissipation (Flash devices in QFP package) [4] PD - 430[5] mW TA=105oC - 750[5] mW TA=90oC - 540[5] mW TA=125oC, no Flash program/erase [6] Permitted Power dissipation (MB96F346/F347/F348 in LQFP package) [4] PD - 375[5] mW TA=105oC - 750[5] mW TA=85oC - 470[5] mW TA=125oC, no Flash program/erase [6] - 560[5] mW TA=120oC, no Flash program/erase [6] Permitted Power dissipation (MB96F345 in LQFP package) [4] PD - 335[5] mW TA=105oC - 670[5] mW TA=85oC - 840[5] mW TA=75oC - 420[5] mW TA=125oC, no Flash program/erase [6] - 590[5] mW TA=115oC, no Flash program/erase [6] |
|
