MB96340 Series
Document Number: 002-04579 Rev. *A
Page 22 of 109
9. User ROM Memory Map for Mask ROM Devices
MB96345
MB96346
CPU address
ROM size
160kByte
ROM size
288kByte
FF:FFFFH
FF:0000H
128K ROM
256K ROM
FE:FFFFH
FE:0000H
FD:FFFFH
FD:0000H
Reserved
FC:FFFFH
FC:0000H
FB:FFFFH
E0:0000H
External bus
External bus
DF:FFFFH
DF:8000H
Reserved
Reserved
DF:7FFFH
DF:0080H
32K ROM
32K ROM
DF:007FH
DF:0000H
ROM configuration
block RCB
ROM configuration
block RCB
DE:FFFFH
DE:0000H
Reserved
Reserved
