background image
MB96340 Series
Document Number: 002-04579 Rev. *A
Page 48 of 109
000801H
CAN1 - Control register High (reserved)
CTRLRH1
R
000802H
CAN1 - Status register Low
STATRL1
STATR1
R/W
000803H
CAN1 - Status register High (reserved)
STATRH1
R
000804H
CAN1 - Error Counter Low (Transmit)
ERRCNTL1
ERRCNT1
R
000805H
CAN1 - Error Counter High (Receive)
ERRCNTH1
R
000806H
CAN1 - Bit Timing Register Low
BTRL1
BTR1
R/W
000807H
CAN1 - Bit Timing Register High
BTRH1
R/W
000808H
CAN1 - Interrupt Register Low
INTRL1
INTR1
R
000809H
CAN1 - Interrupt Register High
INTRH1
R
00080AH
CAN1 - Test Register Low
TESTRL1
TESTR1
R/W
00080BH
CAN1 - Test Register High (reserved)
TESTRH1
R
00080CH
CAN1 - BRP Extension register Low
BRPERL1
BRPER1
R/W
00080DH
CAN1 - BRP Extension register High (reserved)
BRPERH1
R
00080EH-00080FH
Reserved
-
000810H
CAN1 - IF1 Command request register Low
IF1CREQL1
IF1CREQ1
R/W
000811H
CAN1 - IF1 Command request register High
IF1CREQH1
R/W
000812H
CAN1 - IF1 Command Mask register Low
IF1CMSKL1
IF1CMSK1
R/W
000813H
CAN1 - IF1 Command Mask register High (reserved)
IF1CMSKH1
R
000814H
CAN1 - IF1 Mask 1 Register Low
IF1MSK1L1
IF1MSK11
R/W
000815H
CAN1 - IF1 Mask 1 Register High
IF1MSK1H1
R/W
000816H
CAN1 - IF1 Mask 2 Register Low
IF1MSK2L1
IF1MSK21
R/W
000817H
CAN1 - IF1 Mask 2 Register High
IF1MSK2H1
R/W
000818H
CAN1 - IF1 Arbitration 1 Register Low
IF1ARB1L1
IF1ARB11
R/W
000819H
CAN1 - IF1 Arbitration 1 Register High
IF1ARB1H1
R/W
00081AH
CAN1 - IF1 Arbitration 2 Register Low
IF1ARB2L1
IF1ARB21
R/W
00081BH
CAN1 - IF1 Arbitration 2 Register High
IF1ARB2H1
R/W
00081CH
CAN1 - IF1 Message Control Register Low
IF1MCTRL1
IF1MCTR1
R/W
00081DH
CAN1 - IF1 Message Control Register High
IF1MCTRH1
R/W
00081EH
CAN1 - IF1 Data A1 Low
IF1DTA1L1
IF1DTA11
R/W
00081FH
CAN1 - IF1 Data A1 High
IF1DTA1H1
R/W
000820H
CAN1 - IF1 Data A2 Low
IF1DTA2L1
IF1DTA21
R/W
000821H
CAN1 - IF1 Data A2 High
IF1DTA2H1
R/W
Table 4: I/O map MB96(F)34x
Address
Register
Abbreviation
8-bit access
Abbreviation
16-bit access
Access
