MB96340 Series

Document Number: 002-04579 Rev. *A

Page 64 of 109

Power supply

current in Run

modes[1]

ICCRCH

RC Run mode with CLKS1/2 = CLKB =

CLKP1/2 = 2MHz

(CLKMC, CLKPLL and CLKSC stopped)

+25°C

2.9

Flash devices at 1 Flash wait

state

+125°C

3.5

6.5

+25°C

1.7

2.7

MB96345/346 at 1 ROM wait

state

+125°C

2.3

4.7

ICCRCL

RC Run mode with CLKS1/2 = CLKB =

CLKP1/2 = 100kHz,

SMCR:LPMS = 0

(CLKMC, CLKPLL and CLKSC stopped.

Voltage regulator in high power mode)

+25°C

0.4

0.6

MB96F346/F347/F348 at 1

Flash wait state

+125°C

0.9

3.5

+25°C

0.18

0.3

MB96F345 at 1 Flash wait state

+125°C

0.68

3.3

+25°C

0.4

0.6

MB96345/346 at 1 ROM wait

state

+125°C

0.9

2.4

RC Run mode with CLKS1/2 = CLKB =

CLKP1/2 = 100kHz,

SMCR:LPMS = 1

(CLKMC, CLKPLL and CLKSC stopped.

Voltage regulator in low power mode, no

Flash programming/erasing allowed)

+25°C

0.15

0.25

Flash devices at 1 Flash wait

state

+125°C

0.65

3.2

+25°C

0.15

0.25

MB96345/346 at 1 ROM wait

state

+125°C

0.65

2.1

ICCSUB

Sub Run mode with CLKS1/2 = CLKB =

CLKP1/2 = 32kHz

(CLKMC, CLKPLL and CLKRC stopped,

no Flash programming/erasing allowed)

+25°C

0.1

0.2

Flash devices at 1 Flash wait

state

+125°C

0.6

+25°C

0.1

0.2

MB96345/346 at 1 ROM wait

state

+125°C

0.6

(TA = -40°C to 125°C, VCC = AVCC = 3.0V to 5.5V, VSS = AVSS = 0V)

Parameter

Symbol

Condition (at TA)

Value

Remarks

Typ

Max

Unit
