MB96340 Series

Document Number: 002-04579 Rev. *A

Page 11 of 109

4. Pin Function Description

Table 1: Pin Function description

Pin name

Feature

Description

ADn

External bus

External bus interface (multiplexed mode) address output and data

input/output

ADTG

ADC

A/D converter trigger input

ADTG_R

ADC

Relocated A/D converter trigger input

ALARMn

Alarm comparator

Alarm Comparator n input

ALE

External bus

External bus Address Latch Enable output

External bus

External bus address output

ANn

ADC

A/D converter channel n input

AVCC

Supply

Analog circuits power supply

AVRH

ADC

A/D converter high reference voltage input

AVRH2

ADC

Alternative A/D converter high reference voltage input

AVRL

ADC

A/D converter low reference voltage input

AVSS

Supply

Analog circuits power supply

Voltage regulator

Internally regulated power supply stabilization capacitor pin

CKOTn

Clock output function

Clock Output function n output

CKOTXn

Clock output function

Clock Output function n inverted output

ECLK

External bus

External bus clock output

CSn

External bus

External bus chip select n output

FRCKn

Free Running Timer

Free Running Timer n input

HAKX

External bus

External bus Hold Acknowledge

HRQ

External bus

External bus Hold Request

INn

ICU

Input Capture Unit n input

INTn

External Interrupt

External Interrupt n input

INTn_R

External Interrupt

Relocated External Interrupt n input

LBX

External bus

External Bus Interface Lower Byte select strobe output

MDn

Core

Input pins for specifying the operating mode.

NMI

External Interrupt

Non-Maskable Interrupt input

NMI_R

External Interrupt

Relocated Non-Maskable Interrupt input

OUTn

OCU

Output Compare Unit n waveform output

Pxx_n

GPIO

General purpose IO

PPGn

PPG

Programmable Pulse Generator n output

RDX

External bus

External bus interface read strobe output
