13 / 109 page  MB96340 Series Document Number: 002-04579 Rev. *A Page 13 of 109 5. Pin Circuit Type [1]: Please refer to “ I/O Circuit Type” for details on the I/O circuit types [2]: Devices with suffix ”W” [3]: Devices without suffix ”W” Table 2: Pin circuit types FPT-100P-M20 FPT-100P-M22 Pin no. Circuit type [1] Pin no. Circuit type [1] 1-10 H 1-12 H 11,12 B [2] 13, 14 B [2] 11,12 H [3] 13, 14 H [3] 13,14 Supply 15,16 Supply 15 F 17 F 16,17 H 18,19 H 18-21 N 20-23 N 22-29 I 24-31 I 30 Supply 32 Supply 31-32 G 33-34 G 33 Supply 35 Supply 34 to 41 I 36 to 43 I 42 Supply 44 Supply 43 to 48 I 45 to 50 I 49 to 51 C 51 to 53 C 52 E 54 E 53 to 54 I 55 to 56 I 55 to 62 H 57 to 64 H 63, 64 Supply 65, 66 Supply 65 to 87 H 67 to 89 H 88,89 Supply 90, 91 Supply 90, 91 A 92, 93 A 92-100 H 94 to 100 H |
|
