MB96340 Series
Document Number: 002-04579 Rev. *A
Page 6 of 109
1. Product Lineup
Features
MB96V300B
MB96(F)34x
Product type
Evaluation sample
Flash product: MB96F34x Mask ROM product: MB9634x
Product options
YS
NA
Low voltage reset persistently on / Single clock
RS
Low voltage reset can be disabled / Single clock
YW
Low voltage reset persistently on / Dual clock
RW
Low voltage reset can be disabled / Dual clock
TS
indep. 32KB Flash / Low voltage reset persistently on / Single clock
HS
indep. 32KB Flash / Low voltage reset can be disabled / Single clock
TW
indep. 32KB Flash / Low voltage reset persistently on / Dual clock
HW
indep. 32KB Flash / Low voltage reset can be disabled / Dual clock
FS
64KB Data Flash / Low voltage reset persistently on / Single clock
DS
64KB Data Flash / Low voltage reset can be disabled / Single clock
FW
64KB Data Flash / Low voltage reset persistently on / Dual clock
DW
64KB Data Flash / Low voltage reset can be disabled / Dual clock
AS
No CAN / Low voltage reset can be disabled / Single clock devices
CS
No CAN / indep. 32KB Flash / Low voltage reset can be disabled / Single clock
AW
No CAN / Low voltage reset can be disabled / Dual clock
CW
No CAN / indep. 32KB Flash / Low voltage reset can be disabled / Dual clock
Flash/ROM
RAM
160KB
8KB
ROM/Flash memory
emulation by external
RAM, 92KB internal
RAM
MB96345Y [1], MB96345R [1]
224KB
[Flash A: 160KB, Data
Flash A: 64KB]
8KB
MB96F345F [1], MB96F345D [1]
288KB
16KB
MB96F346Y, MB96346Y [1], MB96F346R, MB96346R [1], MB96F346A
416KB
16KB
MB96F347Y, MB96F347R, MB96F347A
544KB
24KB
MB96F348Y, MB96F348R, MB96F348A
576KB
[Flash A: 544KB, Flash
B: 32KB]
24KB
MB96F348T, MB96F348H, MB96F348C
Package
BGA416
FPT-100P-M20
FPT-100P-M22
DMA
16 channels
6 channels
USART
10 channels
7 channels
