MB96F348CWCPMC-GSE2 Datasheet(PDF) 32 Page - Cypress Semiconductor |
|
|
|||||||||||||||||||||||||||||
MB96F348CWCPMC-GSE2 Datasheet(HTML) 32 Page - Cypress Semiconductor |
|
|
32 / 109 page  MB96340 Series Document Number: 002-04579 Rev. *A Page 32 of 109 000114H DMA2 - I/O register address pointer low byte IOAL2 IOA2 R/W 000115H DMA2 - I/O register address pointer high byte IOAH2 R/W 000116H DMA2 - Data counter low byte DCTL2 DCT2 R/W 000117H DMA2 - Data counter high byte DCTH2 R/W 000118H DMA3 - Buffer address pointer low byte BAPL3 R/W 000119H DMA3 - Buffer address pointer middle byte BAPM3 R/W 00011AH DMA3 - Buffer address pointer high byte BAPH3 R/W 00011BH DMA3 - DMA control register DMACS3 R/W 00011CH DMA3 - I/O register address pointer low byte IOAL3 IOA3 R/W 00011DH DMA3 - I/O register address pointer high byte IOAH3 R/W 00011EH DMA3 - Data counter low byte DCTL3 DCT3 R/W 00011FH DMA3 - Data counter high byte DCTH3 R/W 000120H DMA4 - Buffer address pointer low byte BAPL4 R/W 000121H DMA4 - Buffer address pointer middle byte BAPM4 R/W 000122H DMA4 - Buffer address pointer high byte BAPH4 R/W 000123H DMA4 - DMA control register DMACS4 R/W 000124H DMA4 - I/O register address pointer low byte IOAL4 IOA4 R/W 000125H DMA4 - I/O register address pointer high byte IOAH4 R/W 000126H DMA4 - Data counter low byte DCTL4 DCT4 R/W 000127H DMA4 - Data counter high byte DCTH4 R/W 000128H DMA5 - Buffer address pointer low byte BAPL5 R/W 000129H DMA5 - Buffer address pointer middle byte BAPM5 R/W 00012AH DMA5 - Buffer address pointer high byte BAPH5 R/W 00012BH DMA5 - DMA control register DMACS5 R/W 00012CH DMA5 - I/O register address pointer low byte IOAL5 IOA5 R/W 00012DH DMA5 - I/O register address pointer high byte IOAH5 R/W 00012EH DMA5 - Data counter low byte DCTL5 DCT5 R/W 00012FH DMA5 - Data counter high byte DCTH5 R/W 000130H-00017FH Reserved - 000180H-00037FH CPU - General Purpose registers (RAM access) GPR_RAM R/W 000380H DMA0 - Interrupt select DISEL0 R/W 000381H DMA1 - Interrupt select DISEL1 R/W Table 4: I/O map MB96(F)34x Address Register Abbreviation 8-bit access Abbreviation 16-bit access Access |
|
