background image
MB96340 Series
Document Number: 002-04579 Rev. *A
Page 23 of 109
10. Serial Programming Communication Interface
Note: If a Flash programmer and its software needs to use a handshaking pin, Cypress suggests to the tool vendor
to support at least port P00_1 on pin 76/78.If handshaking is used by the tool but P00_1 is not available in customer’s
application, Cypress suggests to the customer to check the tool manual or to contact the tool vendor for alternative
handshaking pins.
Table 3: USART pins for Flash serial programming (MD[2:0] = 010, Serial
Communication mode)
MB96F34x
Pin number
Pin number
USART Number
Normal function
LQFP-100
QFP-100
57
59
USART0
SIN0
58
60
SOT0
59
61
SCK0
60
62
USART1
SIN1
61
63
SOT1
62
64
SCK1
22
24
USART2
SIN2
23
25
SOT2
24
26
SCK2
85
87
USART3
SIN3
86
88
SOT3
87
89
SCK3
